Products
-
Suppleful, mild, neutral comfort
chromeli with no choice of scenes -
Hybrid machine with sharp acceleration
and sharp handling, excellent runability -
Luxurious titanium minibello that combines sharp, sharp sports performance and comfort
-
Pure sports racer can
experience agile activity
Slant Design
A slender, beautiful and attractive design in a simple form that you will not get bored off.
From development to manufacturing, all done in the our own factory under strict details and control. The frame design has a common design code which is the “slant design” adopting the two narrow inclined pipes sandwiching the top tube. The silhouette of the impressive frame design not only lie in the design, but also on the unique minivelo framework that will contribute to increase the strength of the entire frame as well as the rigidity around the long head tube. It is a bike that stands out for its handling, and with its slim chromoly body, the CX and CXS is for the rider that wants a soft and comfortable ride.
REYNOLDS Chromoly Tubing
Reynold’s which is famous for producing high performance steel pipe tubing is the supplier for our main frame tubing. We use the Reynold’s 525 Chromoly Butted Tube which is from 6mm to 31.8mm in diameter to create the slim and sharper look.
Powder Coating Paint
Powder coating by Kadowaki Coating (Yokohama City, Kanagawa Prefecture) creates a beautiful and durable paint finish.
Full Domestic Production
Everything from development to manufacturing is done domestically, under strict quality and accuracy control system. Each piece is done part by part by our craftsmen with emphasis on accuracy and detail to show our the commitment in producing the CX and CXS.
TIG (Tungsten Inert Gas) welding at the joints of tubes and powder coating on the frame is like an art itself. This high quality bike can only be produced by hand, one piece at a time.
Features
All the frames are produced at our own factory in Kagawa prefecture. A slim and beautiful silhouette that complements the rider, a simple design that you do not get bored off.
A smooth and high-quality ride produced from the steel frame surely puts a smile on your face on every ride.
Main features
· Frames made under strict quality control and complete production at our factory
· High grade, lightweight and seamless chromoly Reynolds 525 tubing
· Beautiful slender tubes
· Frame design fully compatible with latest drive train components
· Full carbon monocoque fork for light and comfortable ride
· Powder coating by Kadowaki Coating Company for the perfect paint finish and durability. Custom colours available on request.
· High-performance AM3 wheels with sealed bearing hub
· Low center of gravity and long wheel base for stable riding
· A wide range of specifications are available, from handlebar type to drive train
· Stolen recovery support
ベアリング内蔵BBホビット・クランクセット2
BB周りの剛性を確保するために、BB下のにベアリング内蔵のピポットを設計。これを回転軸に、リアホイールが、180°展開します。その際、折畳み時のチェーン脱落を考慮し、56T・CNC製のチェーンガードを装着。標準仕様は、53Tのシングルチェーンリング、ホローテック方式のクランク・BBの採用。
ベアリング内蔵BBホビット・クランクセット2
BB周りの剛性を確保するために、BB下のにベアリング内蔵のピポットを設計。これを回転軸に、リアホイールが、180°展開します。その際、折畳み時のチェーン脱落を考慮し、56T・CNC製のチェーンガードを装着。標準仕様は、53Tのシングルチェーンリング、ホローテック方式のクランク・BBの採用。
Comfortable and Supple Ride
Due to the low center of gravity and long wheel base, the CX and CXS thoroughly eliminates that wobbly reign feeling that is common among small wheel bicycles. In addition when the design is made using Chromoly, it further enhances the sense of stability and rigidity of the slant tubing and at the same time create a supple and comfortable ride. This bike for all riding style, be it in the city, scenic or back to nature route.
Light Weight Full Carbon Monocoque Fork
A lightweight full carbon monocoque fork which is excellent for vibration absorption is used for delivering a light and comfortable ride.
High Performance AM-3 Wheels
Lightweight, high-performance wheel with sealed bearing hub (AM-3) on the 20 inch 451 size delivers excellent rotation performance and unique riding experience.In addition, you can opt to upgrade to a higher grade wheels, the AM – 9 Plus which churns out even better riding performance.
仕様
Geometry
CX
A Wheel base: 1,045 mm
B Seat tube length (C – T): 405 mm
C Virtual top tube length (horizontal): 545 mm
D Head tube angle: 70.5 °
E Seat tube angle: 73.5 °
F Chain stay length: 430 mm
G Bottom bracket height: 272 mm
H Total length: 1,554 mm
CXS
A Wheelbase: 1,004 mm
B Seat tube length (C – T): 405 mm
C Virtual top tube length (horizontal): 511 mm
D Head tube angle: 69.5 °
E Seat tube angle: 72.5 °
F Chain stay length: 425 mm
G Bottom bracket height: 269 mm
H Total length: 1,526 mm ”
Main Specifications：
· Frame: Reynolds # 525 Cromoly Double Butted Tube
· Wheel: 20 inches (ETRTO 451)
· Standard color: Kadowaki Powder coating
· CX, CXS; Pastel Blue M (New Color) / Sulfur Yellow / Spark Iron Medium Matte / Kasumi Light Gray Matte (New Color)
· Fork: Carbon monocoque fork
· Brake: Caliper brake
· Shift: 9 speed ~ 2 x 11 speed (depending on model)
– Frame weight: CX / 3, 100 g, CXS / 2, 800 g * Weight including frame, fork, head parts, top cover
· Completed car weight: 9.0 kg (excluding pedals) * CX drop handle model
· CX adaptation height of about 160 to 180 cm
· CXS adaptation height 145 cm ~ 165 cm (frame reach: 356.3 mm / stack height: 381.5 mm)
※ However, depending on the physique and the riding history on sports bikes etc.
CXS Flat model Specification CXS Drop model Specification
CX Flat model Specification CX Drop model Specification
Equipment / Components / CX, CXS Shimano Tiagra Flat Single Model：
· Wheel set: AM-3 451 Silver, F24 R2 8H
· Tire: SCHWALBE DURANO 20 “x 11/8 (451 x 28)
· Rear derailleur: RD-4700SS
· Shifter: SL-4700
· Cassette: CS-HG500-10 / 11-25T, 10speed
· Chain: CN-HG 54/10 speed
· Crankset: Tyrell original 53T L170 mm (CXS is L 165 mm)
· Brake calipers: TEKTRO
· Saddle: Genuine Tyrell
· Seatpost: # 7075 Alloy D 27.2 x 400 mm Black
· Stem: Tyrell MR stem 25.4 mm × 100 mm (CXS load stem 31.8 mm × 80 mm)
· Handlebar: Tyrell #6061 Aluminum 510 mm × 25.4 mm (CXS is aluminum 560 mm × 25.4 mm) ”
CXS
・CXS for The Petite
Based on the basic performance of CX, CXS optimizes the size and specification so that petite people can also enjoy it. The comfort produces from the steel frame is left intact, but by reforming the geometry to suit the petite it makes the CXS more suitable, comfortable, easier to control and handle.
・CXS Original Parts
We offer special parts to optimize the riding position for petite people, such as 15 ° sweep handle, 360 mm wide short reach drop handlebar and the 80mm short stem.
Others
・Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The CXS is compatible with all the latest drive trains, so it i s possible to just purchase the frame and custom build the CX or CXS with parts of your choice.
・Theft Recovery Support
Our theft recovery support will enable you to repurchase a new CX or CXS (only once) at a lower price if the theft occurs inside one year from the date of purchase.
・Custom Colour Order
Frame colors can be painted in your favorite colors (charged option). You can choose the color of the decal too to make the CX or CXS truly personalised.
標準カラー:
オプション：
Custom Colour Order
Frame colors can be painted in your favorite colors (charged option). You can choose the color of the decal too to make the RX truly personalised.
Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The FX is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the FX with parts of your choice.
CSI.The Spartan
Fast acceleration
and sharp handling.
CSI is the ultimate hybrid minivelo.
Slant Design
CSI is designed by weaving together a distinctive thin large diameter aluminium frame and beautiful carbon rear triangle.
A utility bike endorsed by riders due to its performance and sharpness because of its super lightweight body and specifications. The frame design has a common design code which is the “slant design” adopting the two narrow inclined pipes sandwiching the top tube. The silhouette of the impressive frame design not only lies in the design, but also on the unique minivelo framework that will contribute to increase the strength of the entire frame as well as the rigidity around the long head tube. High torsional rigidity due to this slant effect and low center of gravity because of the geometry plus using the strongest yet lightweight #7005 aluminium alloy series and pair it with a rear carbon triangle will create an explosive acceleration feeling and sharp handling which road bike’s cannot give. The CSI is compatible to install the Shimano Di2 electronic drive train. It’s smooth, beautiful welding and attention to detail is the perfect one for those who pursues real fun.
Attractive Frame Design
“Slant Tube” is when two tubes extending from the head tube to the top tube creates an exceptional beauty when viewed from the back. Furthermore, the unique shape down tube enhances the rigidity which is the uniqueness of the CSI.
Craftsmanship Detailing
The smooth welding on the aluminium 7005 frame for light weight and high rigidness requires the welding beads to be carefully polished. This attention to the smallest details is to ensure the CSI is beautifully and skilfully done.
The New Carbon Rear Triangle
Using carbon material for high vibration absorbing purposes on the chain and seat stay, also adds to the beauty of the CSI.
Around the BB Design
Three places around the bottom bracket are welded to increase the frame strength. The Chainstay which is fixed by a special adhesive, brings out a tremendous rigid feeling beyond imagination.
Features
The main frame is made from aluminium 7005 material and using full carbon rear triangle, create a light weight with super vibration absorption minivelo that is performance ready.
Main features
· Lightweight Hybrid 7005 Aluminum Frame & Carbon Rear Triangle
· Frame design compatible to fit all road drive trains
· Craftsmanship in the detailed welding finish and top of with Kadowaki powder coating
· Ideal frame for both light weight and high rigidity
· Unique shaped down tube to increase rigidity
· Full carbon monocoque fork that promises lightweight and ride comfort
· High-performance AM3 wheels with sealed bearing hub
· Di2 ready with internal wiring
· Low center of gravity and long wheel base for stable riding
· A wide range of specifications are available according to the riding style, from handlebar types to different drive train settings
· Stolen recovery support support
高性能ホイール、AM-3を標準装備
シールドベアリングハブ搭載の軽量・高性能ホイールを標準装備（AM-3）。抜群の回転性能と、20インチ451サイズならではの走破性を活かした走りを味わえます。また、追加オプションで上位グレードのホイールへアップグレード（AM-9 Plus）も可能、走りの性能がさらに高まります。
精悍さをアピールする、ツートンカラー
2020イヤーモデルは、レーシーな面持ちのCSiをさらに際立たせる、グロス（艶あり）とマットブラック（艶なし）のツートンカラー。グロス部分は、4色の中からあなたのセンスに合ったカラーをお選びいただけます。
Di2コンポ対応
フレームアタッチメントを交換すれば、最新のシマノDi2コンポーネントにも対応可能。エレクトリックケーブルもフレーム内にすっきりと内蔵できます。
The Lightness
High torsional rigidity by the slant tube with low center of gravity and long wheel base allows you to enjoy a sense of stability on the CSI.
In addition, by pairing the rigid aluminium frame with the flexibility of carbon to create a light weight frame makes acceleration on the CSI a truly enjoyable feeling.
Lightweight Full Carbon Monocoque Fork
A lightweight full carbon monocoque fork which is excellent for vibration absorption is used for delivering a light and comfortable ride.
High-Performance AM-3 Wheels
Lightweight, high-performance wheel with sealed bearing hub (AM-3) on the 20 inch 451 size delivers excellent rotation performance and unique riding experience.In addition, you can opt to upgrade to a higher grade wheels, the AM – 9 Plus which churns out even better riding performance.”
Equipped with High End Shimano Components
The standard CSI is equipped with high-grade Shimano Ultegra R8000 series, which is smooth, reliable and robust to compliment the CSI.
仕様
Geometry
A Wheelbase: 1,034 mm
B Seat tube length (C – T): 405 mm
C Virtual top tube length (horizontal): 545 mm
D Head tube angle: 71.0 °
E Seat tube angle: 73.5 °
F Chain stay length: 425 mm
G Bottom bracket height: 272 mm
H Total length: 1,545 mm
Main Specifications：
· Frame: Aluminum #7005 Double Butted Tube
· Wheel: 20 inches (ETRTO 451) O.L.D: F 100 mm / R130 mm
· Fork: 3K carbon monocoque
· Speed change: 11 speed
· Frame weight: 2,150 g * Weight including frame, fork, head part, top cover
· Complete weight (not including pedals): 7.5 kg (drop handlebar model)
Flat model Specification Drop model Specification
Equipment / Components / Shimano ULTEGRA R8000 drop model：
· Wheel set: AM-3 451 Silver, F24 R2 8H
· Tire: SCHWALBE DURANO 20 “x 11/8 (451 x 28)
· Front derailleur: Shimano ULTEGRA FD-R 8000
· Rear derailleur: Shimano ULTEGRA RD – R 8000 11 Speed
· Shifter: Shimano ULTEGRA ST-R 8000
· Cassette: Shimano ULTEGRA CS-R 800011-25T 11 speed
· Chain: CN-HG 701 – 11
· Crankset: Crankset: Shimano ULTEGRA FC-R 8000 53 x 39 T 170 mm
· Brake caliper: Shimano ULTEGRA BR-R 8000
· Saddle: Prologo NAGO EVO T1.4
· Seatpost: # 7075 Alloy, D 31.6 x 400 mm
· Stem: Tyrell Road Stem 31.8 x L 80/90/100/110 mm
· Handlebar: Tyrell #7050 Aluminum d 31.8 x W 360 mm / 380 mm / 400 mm / 420 mm
Custom Specification ：
・It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The CSI is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the CSI with parts of your choice.
・Theft Recovery Support
Our theft recovery support will enable you to repurchase a new CSI (only once) at a lower price if the theft occurs inside one year from the date of purchase.
Standard color:
オプション：
[PURCHASE ONLY FROM JAPAN DOMESTIC CUSTOMER]
Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The FX is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the FX with parts of your choice.
PKZ Comfort Oriented
Lavish Mini Velo
Combines sportiness and comfort with a sharp
and unique seat stay shape. The supreme minivelo
PKZ made with high-grade titanium material
Slant Design
PKZ is one of our flagship models that is attractive in shining titanium and beautifully crafted. It brings performance with superior comfort beyond the comparison of any other minivelos. Made using high-grade titanium alloy which is used for the aerospace industry, it creates a bike with high rigidity and yet lightweight.
The frame design has a common design code which is the “slant design” adopting the two narrow inclined pipes sandwiching the top tube. The silhouette of the impressive frame design not only lies in the design, but also on the unique minivelo framework that will contribute in increase of the strength of the entire frame as well as the rigidity around the long head tube. High torsional rigidity due to this slant effect and low center of gravity because of the geometry, plus using the power of the titanium material will create an explosive performance feeling with a sense of stability. Furthermore, the unique shape titanium yoke placed on the seat stay attenuates the vibration from the rear wheel moderately. It produces a soft tail effect and you can enjoy a unique riding feeling. The PKZ is compatible to install the Shimano Di2 electronic drive train. The attention it creates from its hair line finishing and framework is no wonder it is the pinnacle of a minivelo, a bike for life time.
Ti3Al2.5V Double Butted Tube
The main frame is made with high-grade TITANIUM 3 Al 2.5 V tubing used in aviation industry. The titanium frame not only produces a rugged and comfortable ride it does not corrode and rust. It is one of the best material for bicycle frames too.
The PKZ frames are designed to be lightweight and robust, thus we use thin titanium tubes of 0.8 t – 0.5 t – 0.8 t in thickness and create a double butted down tube and top tube.
Attractive Frame Design
Two tubes extending from the head tube, the “Slant Tube” design create an exceptional beauty when viewed from the back. Plus an attractive titanium color with hairline finish makes it a true work of art.
Tough & Beautiful Welding
All titanium tubes are smoothly and firmly welded by smooth welding method. Incorporating two Tig welding, the PKZ frame is completed through a labor-intensive process of polishing the welding bits.
High Precision & Excellent Design
To process the Titanium such as cutting and bending requires more skill than aluminium and iron. After machining the tube to the dimensions as drawn, accurate alignment check is done before the welding process. Thus to produce the PKZ, it requires utmost precision.
Features
PKZ like the PK1, is derived from the name of Philip Kindred Dick, who is a famous science fiction writer. He is renowned for the movie “Blade Runner”. This movie was the trigger of the birth of “Tyrell”.
The “Z” is to ensure Tyrell will have a long brand life till the end of time.
Main features
· Adopted double-butted tube made of high grade TITANIUM 3Al 2.5V
· Frame design fully compatible with all drive trains
· The Titanium frame is also an elegant shaped piece of art.
· Ideal frame as it is lightweight and high rigidity
· Beautiful hairline finish that further highlights the glow of the titanium
· Full carbon monocoque fork that promises lightweight and comfort
· Equipped with the highest grade wheel “AM-9 Plus” with sealed bearing hubs
· “Tyrell Premium Coat” compatible as we use Crest Yondo’s coating service to improve antifouling and give that glossy feeling
· Supports Di2 component with internal cabling
· Low center of gravity and long wheel base for stable riding.
· A wide range of specifications are available according to the style of ride, from handlebar type to drive trains
· Stolen recovery support
個性に応じて選べるハンドル、コンポーネント
ライダーの走りと個性に応じ、さまざまなハンドル形状、コンポーネントから選択が可能です。（写真はDi2ブルホーンモデル）
高級感をアップするチタン製パーツ
チタニウム3Al2.5V製のシートポストとシートクランプを標準装備。ポリッシュ仕上げの光沢が、より一層のプレミアム感を演出します。
Flexible & Stable
Due to the low center of gravity and long wheel base, the PKZ thoroughly eliminates that wobbly riding feeling that is common among small wheel bicycles. In addition when the design is made using Titanium, it further enhances the sense of stability and rigidity of the slant tubing when riding.
Titanium Yoke for Additional Comfort
At the tip of the S-vent shaped seat stay, we made a CNC machined Titanium yoke in a smooth flowing shape that connects to the top tube. This yoke attenuates vibrations from the rear wheels moderately and produces a soft tail effect and will create a high quality gentle ride feeling on the PKZ.
Light Weight Full Carbon Monocoque Fork
A lightweight full carbon monocoque fork which is excellent for vibration absorption is used for delivering a light and comfortable ride.
CNC Processing for Robustness
We ensure the robustness of the frame by CNC machined titanium block to the shell, head tube, rear end and most importantly the Bottom Bracket that is subjected to the frame stress.
Titanium Parts
Titanium 3A1 2.5V seat post and seat clamp in polished finish are provided to give a more premium feeling.
Geometry
A Wheel base: 1,045 mm
B Seat tube length (C – T): 405 mm
C Virtual top tube length (horizontal): 545 mm
D Head tube angle: 70.5 °
E Seat tube angle: 73.0 °
F Chain stay length: 430 mm
G Bottom bracket height: 272 mm
H Total length: 1,550 mm
Main Specifications：
· Frame: TITANIUM 3Al 2.5V double butted tube
· Wheel: 20 inches (ETRTO 451) O.L.D: F 100 mm / R130 mm
· Fork: Carbon monocoque 20
· Seatpost: ø 31.6 mm compatible
· Shift: 2 * 11 speed
Flat and Drop model Specification Di2 model Specification
Equipment / Components / Shimano ULTEGRA Drop Model
· Wheel set: AM-9Plus gray, F20 R24H / CNC processing rim
· Tires: SCHWALBE DURANO folding 20 “× 1-1 / 8
· Front derailleur: Shimano ULTEGRA FD – R 8000
· Rear derailleur: Shimano ULTEGRA RD – R 8000 – SS
· Dual control lever: Shimano ULTEGRA ST – R 8000
· Cassette: Shimano ULTEGRA CS – R 8000/11 – 28 T 11 speed
· Chain: Shimano ULTEGRA CN – HG 701 – 11
· Crankset: Shimano ULTEGRA FC – R 8000 53 x 39 T 170 mm
· Saddle: Prologo Nago Evo-Ti 1.4 Black
· Seatpost: TYRELL Titanium / 3Al 2.5 V D 31.6 x 400 mm
· Stem: TYRELL RoadStem 31.8 × 90 mm (or 80 mm, 100 mm, 110 mm)
· Brake caliper: Shimano ULTEGRA BR-R 8000
· Handlebar: Tyrell # 7050 Al 31.8 mm x 400 mm (or 360 mm, 380 mm, 420 mm)
Others：
・Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The CSI is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the PKZ with parts of your choice.
・Theft Recovery Support
Our theft recovery support will enable you to repurchase a new PKZ (only once) at a lower price if the theft occurs inside one year from the date of purchase.
・Tyrell Premium Coat（Chargable）
“”Tyrell Premium Coat”” is a coat dedicated exclusively to the titanium frame using Crest Yondo’s coating service called “”Glass Armor”.
The coating is to ensure the PKZ looks new for many years to come as it is abrasion and contamination resistant while easy to clean and looks glossy.
Color:
オプション：
[PURCHASE ONLY FROM JAPAN DOMESTIC CUSTOMER]
Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The FX is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the FX with parts of your choice.
Tyrell Premium Coat（Chargable）
"Tyrell Premium Coat" is a coat dedicated exclusively to the titanium frame using Crest Yondo's coating service called "Glass Armor”. The coating is to ensure the PKZ looks new for many years to come as it is abrasion and contamination resistant while easy to clean and looks glossy.
Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The CSI is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the PKZ with parts of your choice.
Pure Agile
Sports Racer
First minivelo made
using high-grade titanium alloy
for high sports performance
Slant Design
PK1 is one of our flagship models that is attractive in shining titanium and beautifully crafted.
It brings performance with superior comfort beyond the comparison of any other minivelos. Made using high-grade titanium alloy which is used for the aerospace industry, it creates a bike with high rigidity and yet lightweight. The frame design has a common design code which is the “slant design” adopting the two narrow inclined pipes sandwiching the top tube. The silhouette of the impressive frame design not only lies in the design, but also on the unique minivelo framework that will contribute to increase the strength of the entire frame as well as the rigidity around the long head tube. High torsional rigidity due to this slant effect and low center of gravity because of the geometry, plus using the power of the titanium material will create an explosive performance feeling with a sense of stability. Beautiful proportions and overwhelming performance of the PK1 will give you a new dimension in riding a minivelo.
Tough & Beautiful Welding
All titanium tubes are smoothly and firmly welded by smooth welding method. Incorporating two Tig welding, the PKZ frame is completed through a labor-intensive process of polishing the welding bits.
High Precision & Excellent Design
To process the Titanium such as cutting and bending requires more skill than aluminium and iron. After machining the tube to the dimensions as drawn, accurate alignment check is done before the welding process. Thus to produce the PKZ, it requires utmost precision.
Features
PKZ like the PK1, is derived from the name of Philip Kindred Dick, who is a famous science fiction writer. He is renowned for the movie “Blade Runner”. This movie was the trigger of the birth of “Tyrell”.
The “Z” is to ensure Tyrell will have a long brand life till the end of time.
Main features
· Adopted double-butted tube made of high grade TITANIUM 3Al 2.5V
· Frame design fully compatible with all drive trains
· The Titanium frame is also an elegant shaped piece of art.
· Ideal frame as it is lightweight and high rigidity
· Beautiful hairline finish that further highlights the glow of the titanium
· Full carbon monocoque fork that promises lightweight and comfort
· Equipped with the highest grade wheel “AM-9 Plus” with sealed bearing hubs
· “Tyrell Premium Coat” compatible as we use Crest Yondo’s coating service to improve antifouling and give that glossy feeling
· Supports Di2 component with internal cabling
· Low center of gravity and long wheel base for stable riding.
· A wide range of specifications are available according to the style of ride, from handlebar type to drive trains
· Stolen recovery support
Titanium Parts
Titanium 3A1 2.5V seat post and seat clamp in polished finish are provided to give a more premium feeling.
Flexible & Stable
Due to the low center of gravity and long wheel base, the PKZ thoroughly eliminates that wobbly riding feeling that is common among small wheel bicycles. In addition when the design is made using Titanium, it further enhances the sense of stability and rigidity of the slant tubing when riding.
Titanium Yoke for Additional Comfort
At the tip of the S-vent shaped seat stay, we made a CNC machined Titanium yoke in a smooth flowing shape that connects to the top tube. This yoke attenuates vibrations from the rear wheels moderately and produces a soft tail effect and will create a high quality gentle ride feeling on the PKZ.
Light Weight Full Carbon Monocoque Fork
A lightweight full carbon monocoque fork which is excellent for vibration absorption is used for delivering a light and comfortable ride.
Geometry
A Wheel base: 1,045 mm
B Seat tube length (C – T): 405 mm
C Virtual top tube length (horizontal): 545 mm
D Head tube angle: 70.5 °
E Seat tube angle: 73.0 °
F Chain stay length: 430 mm
G Bottom bracket height: 272 mm
H Total length: 1,550 mm
Main Specifications：
· Frame: TITANIUM 3Al 2.5V double butted tube
· Wheel: 20 inches (ETRTO 451) O.L.D: F 100 mm / R130 mm
· Fork: Carbon monocoque 20
· Seatpost: ø 31.6 mm compatible
· Shift: 2 * 11 speed
Flat and Drop model Specification Di2 model specificetion
Equipment / Components / Shimano ULTEGRA Drop Model：
· Wheel set: AM-9Plus gray, F20 R24H / CNC processing rim
· Tires: SCHWALBE DURANO folding 20 “× 1-1 / 8
· Front derailleur: Shimano ULTEGRA FD – R 8000
· Rear derailleur: Shimano ULTEGRA RD – R 8000 – SS
· Dual control lever: Shimano ULTEGRA ST – R 8000
· Cassette: Shimano ULTEGRA CS – R 8000/11 – 28 T 11 speed
· Chain: Shimano ULTEGRA CN – HG 701 – 11
· Crankset: Shimano ULTEGRA FC – R 8000 53 x 39 T 170 mm
· Saddle: Prologo Nago Evo-Ti 1.4 Black
· Seatpost: TYRELL Titanium / 3Al 2.5 V D 31.6 x 400 mm
· Stem: TYRELL RoadStem 31.8 × 90 mm (or 80 mm, 100 mm, 110 mm)
· Brake caliper: Shimano ULTEGRA BR-R 8000
· Handlebar: Tyrell # 7050 Al 31.8 mm x 400 mm (or 360 mm, 380 mm, 420 mm)
Others：
・Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The CSI is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the PKZ with parts of your choice.
・Theft Recovery Support
Our theft recovery support will enable you to repurchase a new PKZ (only once) at a lower price if the theft occurs inside one year from the date of purchase.
・Tyrell Premium Coat（Chargable）
“”Tyrell Premium Coat”” is a coat dedicated exclusively to the titanium frame using Crest Yondo’s coating service called “”Glass Armor”.
The coating is to ensure the PKZ looks new for many years to come as it is abrasion and contamination resistant while easy to clean and looks glossy.
Color:
オプション：
[PURCHASE ONLY FROM JAPAN DOMESTIC CUSTOMER]
Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The FX is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the FX with parts of your choice.
Tyrell Premium Coat（Chargable）
"Tyrell Premium Coat" is a coat dedicated exclusively to the titanium frame using Crest Yondo's coating service called "Glass Armor”. The coating is to ensure the PK1 looks new for many years to come as it is abrasion and contamination resistant while easy to clean and looks glossy.
Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The FX is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the FX with parts of your choice.
-
Premium folding limited to 50 units commemorating the 10th anniversary of Tyrell’s foundation
-
Light weight & high performance folding bike to inherit Tyrell’s DNA
-
Light weight & high performance folding bike to inherit Tyrell’s DNA
-
The fastest and lightest folding that condensed the ultimate running and lightness into a small size
-
Easy, comfortable, high performance compacted in compact size, folding safe to use
-
Easy, comfortable, high performance compacted in compact size, folding safe to use
Ultra Premium
Anniversary Model
In commemoration of the 10th anniversary of Tyrell.
Ultra premium folding bicycles
(50 units only).
Slant Design
A supreme model that is created to commemorate the 10th Anniversary of Tyrell.
Since its inauguration, Tyrell has been the master of folding bicycles worldwide. Compiling all the technologies and know-how for the past ten years and manufacturing using high-grade titanium alloy which is difficult to make, shows the capabilities that we possess ,plus the ultimate knowledge in folding mechanisms to create the XF. The frame design has a common design code which is the “slant design” adopting the two narrow inclined pipes sandwiching the top tube. The silhouette of the impressive frame design not only lies in the design, but also on the unique minivelo framework that will contribute to increase the strength of the entire frame as well as the rigidity around the long head tube. High torsional rigidity due to this slant effect and low center of gravity because of the geometry, plus using the power of the titanium material will create an explosive performance feeling with a sense of stability. In addition, the XF is paired with the best possible components such as Shimano’s top-class electric component DuraAce Di 2 and GOKISO wheels which is renowned as an ultra-high performance wheel maker, to make the XF nto a real masterpiece.
Its presence that surpasses other folding bikes is brought about by the glittering shiny titanium polish. The XF is mainly for those who seek no compromise, and demand the best of the best. Special warranty card and serial number plates are attached to each every unique XF masterpiece.
Exclusively Design for Di2
Various parts and frame are designed exclusively to fit the Shimano’s Di2 system. The frame is built to fit all the electric cables and batteries ensuring the XF looks elegant, neat and smart.
Titanium Emblem
A titanium emblem exclusively for XF on the head tube
Integrated Carbon Handle Bar
Using integrated stem type carbon handle made by Vision (Vision). It stores the Di2 junction smartly and gather it cleanly around the handlebars.
High Technology,
Beautiful Workmanship
Processing the titanium, such as cutting and bending requires more skills than aluminium and iron. The beautiful form of the frame is a proof of Tyrell’s capabilities and craftsmanship.
Features
The combination of technology and design to create the ultimate folding bicycle with overwhelming performance and presence
Main features
· Double-butted tube made of high-grade TITANIUM 3Al 2.5V.
· Adoption of 1-1 / 4 “integrated head tube
· Light weight carbon monocoque folding fork
· Shimano DURA ACE Di2 electric component equipped
· The XF Carbon Wheel boasts extreme rolling performance using exclusively designed GOKISO hubs for XF.
· Excellent riding performance due to low center of gravity
· Hand crafted
· Equipped with high performance Vision integrated stem · Lightweight carbon aero drop bar.
· Special warranty card and serial number plate included
Folding Fork
A bold design that bends 90 degrees from the base of the fork after pulling out the safety pin and loosening the knob. After folding, reinsert the safety pin to lock it. The high rigid folding fork has also passed the durability test is a proof of Tyrell’s superior design technology.
BB Pivot・Crankset
To ensure the rigidity around the BB, we designed a pivot with built-in bearing under the BB for the rear wheel to turn 180 ° around this axis when folded. And in ensuring the chain does not detach during folding, we attached a 56T CNC chain guard.
Excellent Ride Quality
Due to the low center of gravity and long wheel base, the XF thoroughly eliminates that wobbly riding feeling that is common among small wheel bicycles. In addition when the design is made using titanium, it further enhances the sense of stability and rigidity of the slant tubing when riding the XF.
Light Carbon CFRP Full Carbon Fork
XF front forks are made of CFRP monocoque full carbon. With excellent vibration absorption, it reduces vibrations around the front, promising light driving and comfortable ride. Bearings at the bottom of the head tube are 1.25 “ in diameter, contributing to the rigidity of the head tube and the stability of handling.
Shimano DuraAce Di2 Drive Train
Using the pinnacle of Shimano components, the Shimano Durace Di2 ensures you can enjoy comfortable riding without any stress as the drive train has a synchronised shifting that automatically controls the front gear shift and the rear gear shifts.
Geometry
A Wheel base: 1,075 mm
B Seat tube length (C – T): 390 mm
C Virtual top tube length (horizontal): 558 mm
D Head tube angle: 70.0 °
E Seat tube angle: 73.0 °
F Chain stay length: 431 mm
G Bottom bracket height: 273 mm
H Total length: 1,545 mm
Main Specifications：
· Frame: Titanium 3Al 2.5 V double butted tube
· Component: Shimano DURA ACE Di 2
· Wheel: Carbon rim 20 inches (ETRTO 406) + GOKISO special hub
· Folding fork: Full Carbon Monocoque
· Seatpost: 31.6 mm
· Brake: Caliper brakes
· Tires: Schwalbe DURANO Folding 28-406
· Shift: Di2 electric type 11 × 2 speed – Frame weight: 2.4 kg * Weight of frame alone
オプション：
持ち運び
Carry
Unique design philosophy is intact, it can be folded and developed in just tens of seconds
By developing the frame design and original parts, we eliminate negative elements that traditional folding bikes possess, such as minimizing uncomfortable running noise. You do not mind having to worry about carrying around in cars and trains, of course you can also create a stylish atmosphere just by placing them next to the cafe terrace.
Can be carried by car
Go out on the weekend’s day off, driving a little far away. On your favorite spot, ride your favorite bike · · ·. It’s easy to fold, so you can easily carry around with a car.
Can be carried by train
After folding it can be carried comfortably by storing it in a dedicated wheel bag. Because it is a lightweight car body, you can easily travel without stress even in a situation with many scenes to carry.
Can be stored indoors
A height of 79 cm, a length of 87 cm, and a width of 35 cm are realized (in the case of a flat model). Completed car size of 1,075 mm long wheel base is stored in surprisingly compact size. It does not take up space in indoor storage, it not only brings significant benefits to security crime, it can also protect your car from dust and scratches.
Folding procedure
Folding mechanism is designed to folds in just tens of seconds without using any tools. If you want to minimise the width after folding, you can opt for the detachable pedals (available as an optional accessory)
Dedicated wheel bag · Removable pedal on sale
Slant Design
A long-awaited folding bike · The FX was born from Tyrell’s DNA, which pioneered new development for mini-velos.
The frame design has a common Tyrell trademark which is the SLANT Design where two narrow inclined pipes are sandwiched to the top tube. At the first glance, it does not look like a folding bike and yet it folds like an origami transforming itself into a compact elegant folding bike. We at Tyrell are not only working towards creating an impressive and attractive silhouette based on the design, but a unique framework for minivelos as we research ways to increase the strength and rigidness of the entire frame, the improvement of the frame geometry by lowering the center of gravity of the top tube and optimizing the dimensions of the wheel base. No doubt this elements can be solved by adopting the Slant Design, we still need to strive to better the folding mechanism and keep on delivering to you new innovation that can shape the future of folding bikes and minivelos. But for now the FX is the fusion between a great foldable bike with performance and lightness.
Detailed Welding Finishing
Main frame is lightweight #7005 Aluminium double butted tubing. Need a truly committed craftsman to ensure smooth welding and detailing.
Frame Unlike
Any Other Folding Bike
The key point in the development was to make a strong and beautiful folding bike without having moving parts in the main frame. We would like to create a design that from a glance is known to be a Tyrell by incorporating the Slant Design to the FX.
Innovative Folding Fork
The folding fork adopts a backward folding method. This smart design integrates the foldable function of the fork but at the same time securing the strength of it as well. Distinctive use of aluminium and carbon materials on the fork create a light weight foldable fork that is only 900 g.
Unique Original Parts
We at Tyrell express our commitment to every small detail in the design of our bike such as the Aluminium end cap of the grip which is printed with our original logo.
Powder Coating Paint
Powder coating by Kadowaki Coating (Yokohama City, Kanagawa Prefecture) creates a beautiful and durable paint finish.
Features
Smart design using superior production technology to eliminate the weaknesses of folding bikes.
It is a new form of 20 inch folding that combines speed, lightness, and compactness
Main feature
· Lightweight #7005 double butted aluminium tubing
· Frame design fully compatible with any drive train
· Innovative hybrid original design of the folding fork (aluminium & carbon)
· Stylish frame design that does not look like a folding bike
· High-performance wheels with sealed bearing hub
· Ultimate welding craftsmanship
· Powder coating by Kadowaki Coating Company for the perfect paint finish and durability. Custom colours available on request.
· Supports Di2 components with internal cabling
· Low center of gravity and long wheel base for stable riding.
· Extensive optional and spare parts (available for purchase on web store)
· A wide range of specifications are available according to the style of ride, from handle type shape to drive trains
· Colour coordination of parts to produce a custom bike is available on request (This request is chargeable)
· Wheel upgrade possible (chargeable)
· Stolen recovery support
Folding Fork
A bold design that bends 90 degrees from the base of the fork after pulling out the safety pin and loosening the knob. After folding, reinsert the safety pin to lock it. The high rigid folding fork has also passed the durability test is a proof of Tyrell’s superior design technology. "
BB Pivot・Crankset
To ensure the rigidity around the BB, we designed a pivot with built-in bearing under the BB for the rear wheel to turn 180 ° around this axis when folded. And in ensuring the chain does not detach during folding, we attached a 56T CNC chain guard."
シートステージョイント
メインフレームには、折畳みヒンジを設けず、シートステー・チェーンステーを折畳みます。シートステージョイントの安全ピンを抜いて、クイックリリースを緩め、シートステーを外し、180°回転させます。
チェーンガードピン
オフセットさせてた、BBピボットにより、折畳むと、ダウンチューブに重なるように、リアホイールが収納されます。チェーン脱落防止のために、チェーンガードピンを装着。
スピード感、安定感のある走り
低重心、ロングホイールベースなど、考えぬかれたジオメトリーにより、小径車にありがちなふらつきや挙動をできる限り排除。また軽量な車体により、20インチとは思えないスピード感と安定感のある走行が可能です。
走りに貢献する高性能ホイール
シールドベアリングハブ搭載の軽量・高性能ホイールを標準装備（AM-6）。抜群の回転性能と、20インチ406サイズならではの特性を活かした加速性能を味わえます。
Speed, Performance and Stability
Due to the low center of gravity and long wheel base, the FX thoroughly eliminates that wobbly ride feeling that is common among small wheel bicycles. On the FX it is possible to have speed, performance and stability in one bike that no other lightweight 20 inch folding bike can offer.
Folding Function
The FSX folds in just tens seconds with no tools while ensuring great performance. Folded size is 79 cm in height, 87 cm in length and a width of 35 cm. Surprisingly compact for a bike that has a wheelbase of 1,075 mm.
High Performance Wheels
The AM-3 wheels are lightweight, high-performance with sealed bearing hubs. Its excellent rolling and acceleration performance due to the unique characteristics of 20 inch 406 size can be felt on the AM-3. Upgrading to higher grade wheels (AM – 10 Plus) is also possible, with additional costs.
仕様
Geometry
A Wheel base: 1,075 mm
B Seat tube length (C – T): 390 mm
C Virtual top tube length (horizontal): 558 mm
D Head tube angle: 70.0 °
E Seat tube angle: 73.0 °
F Chain stay length: 431 mm
G Bottom bracket height: 273 mm
H Total length: 1,545 mm
Main Specifications：
· Frame: Aluminum #7005 Double Butted Tube
· Wheel: 20 inches (ETRTO 406) O.L.D: F 100 mm / R130 mm
· Folding fork: Carbon blade column length 395 mm
· Speed change: 10 speed (standard flat bar model)
· Frame weight: 3,850 g (※)
· Weight including frame, fork, head part, top cover, seat clamp
· Completed car weight (not including pedals): 9.5 kg (Shimano SORA flat single model)
Flat model Specification Drop model Specification Di2 model Specification
2017 Color:
オプション：
Custom Colour Order
Frame colors can be painted in your favorite colors (charged option). You can choose the color of the decal too to make the RX truly personalised.
Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The FX is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the FX with parts of your choice.
持ち運び
Carry
Unique design philosophy is intact, it can be folded and developed in just tens of seconds
By developing the frame design and original parts, we eliminate negative elements that traditional folding bikes possess, such as minimizing uncomfortable running noise. You do not mind having to worry about carrying around in cars and trains, of course you can also create a stylish atmosphere just by placing them next to the cafe terrace.
Can be carried by car
Go out on the weekend’s day off, driving a little far away. On your favorite spot, ride your favorite bike · · ·. It’s easy to fold, so you can easily carry around with a car.
Can be carried by train
After folding it can be carried comfortably by storing it in a dedicated wheel bag. Because it is a lightweight car body, you can easily travel without stress even in a situation with many scenes to carry.
Can be stored indoors
A height of 79 cm, a length of 87 cm, and a width of 35 cm are realized (in the case of a flat model). Completed car size of 1,075 mm long wheel base is stored in surprisingly compact size. It does not take up space in indoor storage, it not only brings significant benefits to security crime, it can also protect your car from dust and scratches.
Folding procedure
Folding mechanism is designed to fold in just tens of seconds without using any tools. If you want to minimise the width after folding, you can opt for the detachable pedals (available as an optional accessory)
Dedicated wheel bag · Removable pedal on sale
Slant Design
A long-awaited folding bike · The FX was born from Tyrell’s DNA, which pioneered new development for mini-velos.
While keeping the essence of that name machine FX, FXα arranged it at an affordable price.
The frame design has a common Tyrell trademark which is the SLANT Design where two narrow inclined pipes are sandwiched to the top tube. At the first glance, it does not look like a folding bike and yet it folds like an origami transforming itself into a compact elegant folding bike. We at Tyrell are not only working towards creating an impressive and attractive silhouette based on the design, but a unique framework for minivelos as we research ways to increase the strength and rigidness of the entire frame, the improvement of the frame geometry by lowering the center of gravity of the top tube and optimizing the dimensions of the wheel base. No doubt this elements can be solved by adopting the Slant Design, we still need to strive to better the folding mechanism and keep on delivering to you new innovation that can shape the future of folding bikes and minivelos. But for now the FX is the fusion between a great foldable bike with performance and lightness.
Detailed Welding Finishing
Main frame is lightweight #7005 Aluminium double butted tubing. Need a truly committed craftsman to ensure smooth welding and detailing.
Frame Unlike
Any Other Folding Bike
The key point in the development was to make a strong and beautiful folding bike without having moving parts in the main frame. We would like to create a design that from a glance is known to be a Tyrell by incorporating the Slant Design to the FX.
Innovative Folding Fork
The folding fork adopts a backward folding method. This smart design integrates the foldable function of the fork but at the same time securing the strength of it as well. Distinctive use of aluminium and carbon materials on the fork create a light weight foldable fork that is only 900 g.
Equipped with parts over price
Many parts, including the AM-3 wheel, are equipped with the same items as the standard FX. The main component adopts Shimano SORA. We maintain reasonable but satisfactory specs.
Accompanied with fun, separate color acrylic paint
We prepare five kinds of combination colors as standard color lineup, which are divided to front and back. High-quality acrylic paint with beautiful finish, will further motivate ownership possession. (NOTE: FXα will not support custom color order)
Features
Smart design using superior production technology to eliminate the weaknesses of folding bikes.
It is a new form of 20 inch folding that combines speed, lightness, and compactness
Main feature
· Lightweight #7005 double butted aluminium tubing
· Frame design fully compatible with any drive train
· Innovative hybrid original design of the folding fork (aluminium & carbon)
· Stylish frame design that does not look like a folding bike
· High-performance wheels with sealed bearing hub
· Ultimate welding craftsmanship
· Low center of gravity and long wheel base for stable riding.
· Extensive optional and spare parts (available for purchase on web store)
· Stolen recovery support (Domestic only)
Folding Fork
A bold design that bends 90 degrees from the base of the fork after pulling out the safety pin and loosening the knob. After folding, reinsert the safety pin to lock it. The high rigid folding fork has also passed the durability test is a proof of Tyrell’s superior design technology. "
BB Pivot・Crankset
To ensure the rigidity around the BB, we designed a pivot with built-in bearing under the BB for the rear wheel to turn 180 ° around this axis when folded. And in ensuring the chain does not detach during folding, we attached a 56T CNC chain guard."
Seat stay joint
We fold the seat stay & chain stay without setting folding hinges on the main frame, . It's operation is only pull out the safety pin of the seat stay joint, loosen the quick release, and pull over the seat stay and rotate it 180 °.
Chain guard pin
By the BB pivot which was offset, rear wheel is folded so that it overlaps the down tube. The chain guard pin is equipped to prevent the chain from falling off.
Speed feeling, stable running feeling
As the result of our best geometry, such as low center of gravity, long wheel base, we eliminated wobble and behavior that tend to be small wheeled bikes as much as possible. Moreover, lightweight body enabled to travel with a sense of speed and stability that can not be regarded as 20 inches.
High performance wheel that contributes to our ride
Lightweight, high performance wheel with shield bearing hub is equipped as standard (AM-3). You can feel excellent rotation performance and acceleration performance making full use of the unique characteristics of 20 inch 406 size.
Speed, Performance and Stability
Due to the low center of gravity and long wheel base, the FX thoroughly eliminates that wobbly ride feeling that is common among small wheel bicycles. On the FX it is possible to have speed, performance and stability in one bike that no other lightweight 20 inch folding bike can offer.
Folding Function
The FSX folds in just tens seconds with no tools while ensuring great performance. Folded size is 79 cm in height, 87 cm in length and a width of 35 cm. Surprisingly compact for a bike that has a wheelbase of 1,075 mm.
Geometry
A Wheel base: 1,075 mm
B Seat tube length (C – T): 390 mm
C Virtual top tube length (horizontal): 558 mm
D Head tube angle: 70.0 °
E Seat tube angle: 73.0 °
F Chain stay length: 431 mm
G Bottom bracket height: 273 mm
H Total length: 1,545 mm
Main Specifications：
· Frame: Aluminum #7005 Double Butted Tube
· Wheel: 20 inches (ETRTO 406) O.L.D: F 100 mm / R130 mm
· Folding fork: Carbon blade column length 395 mm
· Speed change: 9 speed (standard flat bar model)
· Frame weight: 3,850 g (※)
· Weight including frame, fork, head part, top cover, seat clamp
· Completed car weight (not including pedals): 9.5 kg (Shimano SORA flat single model)
2019 Color:
オプション：
[PURCHASE ONLY FROM JAPAN DOMESTIC CUSTOMER]
Carry
Unique design philosophy is intact, it can be folded and developed in just tens of seconds
By developing the frame design and original parts, we eliminate negative elements that traditional folding bikes possess, such as minimizing uncomfortable running noise. You do not mind having to worry about carrying around in cars and trains, of course you can also create a stylish atmosphere just by placing them next to the cafe terrace.
Can be carried by car
Go out on the weekend’s day off, driving a little far away. On your favorite spot, ride your favorite bike · · ·. It’s easy to fold, so you can easily carry around with a car.
Can be carried by train
After folding it can be carried comfortably by storing it in a dedicated wheel bag. Because it is a lightweight car body, you can easily travel without stress even in a situation with many scenes to carry.
Can be stored indoors
A height of 79 cm, a length of 87 cm, and a width of 35 cm are realized (in the case of a flat model). Completed car size of 1,075 mm long wheel base is stored in surprisingly compact size. It does not take up space in indoor storage, it not only brings significant benefits to security crime, it can also protect your car from dust and scratches.
Folding procedure
Folding mechanism is designed to fold in just tens of seconds without using any tools. If you want to minimise the width after folding, you can opt for the detachable pedals (available as an optional accessory)
Dedicated wheel bag · Removable pedal on sale
Ultimate performance and
lightness in a foldable bike
Fastest & lightest folding,
the FSX
Slant Design
Putting together the best possible way to create an extreme silhouette, light and performance-packed folding bicycle is the drive that created the FSX.
FSX which was born as a superior model to the FX ensures that it inherits the idea and technology cultivated in it but with improved rigidity, weight reduction as well as increase in performance making it the most dynamic and responsive 20” folding bike available.
The frame design has the common Tyrell trademark which is the SLANT Design where two narrow inclined pipes are sandwiched to the top tube. At the first glance, it does not look like a folding bike and yet it folds like an origami transforming itself into a compact elegant folding bike.
The FSX is also designed to be super rigid by eliminating any possible moving parts on the frame as well as using hydrofoamed top and down tubes.
The details in the design such as low centre of gravity, stability while riding due to its long wheel base, internal cabling as well as its unique tubing design and detailed proportion for ultimate riding performance plus the 1st grade powder coating paint by Kadowaki ensures the bike’s colour is beautiful and durable, making it extremely attractive and a must have for folding bike lovers.
With the FSX, riding will always be a pleasure.
Super Rigid Frame Design
The key point in the development was to make a strong and beautiful folding bike without setting moving parts in the main frame. We would like to create a design that from a glance is known to be a Tyrell by incorporating the Slant Design to the FSX. The Slant Design itself is already rigid but when we incorporate hydroforming technology to the top and down tube, the rigidity of the FSX is strengthen even more. And that is how we ensure the FSX is a super rigid designed frame.
Framework Detailing
FSX’s unique framework is attractive and includes hand-welded, smooth and beautiful parts. The hand work also includes sharpening and extraction for the built-in internal cable routings.
Powder Coating Paint
Powder coating by Kadowaki Coating (Yokohama City, Kanagawa Prefecture) creates a beautiful and durable paint finish.
Features
走行時の伸びやかなフォルムと
折りたたみ時のコンパクトさを実現する
オリジナル設計
Main feature
· Lightweight #7005 double butted aluminium tubing
· Frame design fully compatible with any drive train
· Original innovation full carbon folding fork
· Top grade “AM-10 Plus” wheels with sealed bearing hubs
· Stylish frame design that does not look like a folding bike
· Internal cabling on a sophisticated framework similar to premium road racers
· Ultimate welding craftsmanship
· Powder coating by Kadowaki Coating Company for the perfect paint finish and durability. Custom colours available on request.
· Supports Di2 component with internal cabling
· Low center of gravity and long wheel base for stable riding.
· Extensive optional and spare parts (available for purchase on web store)
· A wide range of specifications are available according to the style of ride, from handlebar type to drive trains
· Colour coordination of parts to produce a custom bike is available on request (This request is chargeable)
· Stolen recovery support
Folding Fork
A bold design that bends 90 degrees from the base of the fork after pulling out the safety pin and loosening the knob. After folding, reinsert the safety pin to lock it. The high rigid folding fork has also passed the durability test is a proof of Tyrell’s superior design technology.
BB Pivot・Crankset
To ensure the rigidity around the BB, we designed a pivot with built-in bearing under the BB for the rear wheel to turn 180 ° around this axis when folded. And in ensuring the chain does not detach during folding, we attached a 56T CNC chain guard.
シートステージョイント
メインフレームには、折畳みヒンジを設けず、シートステー・チェーンステーを折畳みます。シートステージョイントの安全ピンを抜いて、クイックリリースを緩め、シートステーを外し、180°回転させます。
チェーンガードピン
オフセットさせてた、BBピボットにより、折畳むと、ダウンチューブに重なるように、リアホイールが収納されます。チェーン脱落防止のために、チェーンガードピンを装着。
Speed, Performance and Stability
Due to the low center of gravity and long wheel base, the FXS thoroughly eliminates that wobbly ride feeling that is common among small wheel bicycles. On the FSX it is possible to have speed, performance and stability in one bike that no other lightweight 20 inch folding bike can offer.
New Design Carbon Monocoque Folding Fork
FSX’s folding forks are all manufactured with CFRP made monocoque. Vibration absorption is greatly enhanced so that the ride comfort is improved. The bearing size at the bottom of the head tube was also increased to 1.25 ”, further increasing the rigidity of the head tube for better handling stability.
Folding Function
The FSX folds in just tens seconds with no tools while ensuring great performance.
Folded size is 79 cm in height, 87 cm in length and a width of 35 cm. Surprisingly compact for a bike that has a wheelbase of 1,075 mm.
Finest Wheels for Ultimate Speed
A high-rolling 20-inch wheel “AM-10 Plus” that brings the performance of FSX to the max by using high rigidity aerodynamic 28mm offset rims with DT Swiss straight pull hub.
Di2 Compatible
Batteries and electric cables can be stored neatly inside the frame and do not damage the beautiful silhouette.
Geometry
A Wheel base: 1,075 mm
B Seat tube length (C – T): 390 mm
C Virtual top tube length (horizontal): 558 mm
D Head tube angle: 70.0 °
E Seat tube angle: 73.0 °
F Chain stay length: 431 mm
G Bottom bracket height: 273 mm
H Total length: 1,545 mm
Main Specifications：
· Frame: Aluminum #7005 Alloy Double Butted Tubing
· Wheel: AM-10 Plus Black 20 inches (28-406)
· Color: Italian Red & Matte Black / Turquoise & Black / Matt Black Metallic by Kadowaki powder coating
· Folding fork: Carbon monocoque
· Speed change: flat bar model 2 × 11 speed, drop bar handle model 2 × 11 speed
· Tires: Schwalbe DURANO Folding 28-406
· Component: Flat bar model Shimano 105 11s, drop handlebar model Shimano Ultegra 11s etc.
· Frame Weight: 3,600 g (※)
· Weight including frame, fork, head part, top cover, seat clamp
· Completed car weight (excluding pedals): 8.5 kg
Flat model Specification Drop model Sprecification Di2 model Specification
FSX 2019 標準カラー（カドワキコーティング製）：
オプション：
Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The FX is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the FX with parts of your choice.
Custom Colour Order
Frame colors can be painted in your favorite colors (charged option). You can choose the color of the decal too to make the RX truly personalised.
持ち運び
Carry
独自の造形フィロソフィはそのままに、わずか数十秒で折り畳みと展開可能な設計
フレーム設計やオリジナルパーツの開発により、耳障りな走行ノイズを最小限にとどめるなど、従来の折り畳み自転車がもつネガティブ要素を徹底的に排除。周りを気にせず車や電車内での持ち運びはもちろん、カフェテラスなどでも隣に置いているだけでスタイリッシュな雰囲気を醸し出してくれることでしょう。
車で運べます
週末のデイオフ、少し遠い場所まで車でお出かけ。お気に入りのスポットで、お気に入りのバイクに乗って・・・。簡単に折り畳めるので、気軽に車での持ち運びが可能です。
※画像は旧モデル（現行モデルと仕様が一部異なる場合がございます。ご注意ください）
電車で運べます
折畳み後は専用の輪行バッグに収納して快適に持ち運びが可能。軽量な車体のため、担ぐシーンの多い状況でもストレスなく楽に輪行できます。
室内での保管にも
高さ79cm、長さ87cm、幅35cmを実現（フラットモデルの場合）。1,075mmのロングホイールベースの完成車サイズが、驚く程コンパクトサイズに収納。室内保管でも場所を取らず、防犯面でも大きなメリットとなるだけでなく、愛車を埃や傷から守ることができます。
折畳み手順
工具不要で、わずか数十秒で折畳めるフォールディングデザイン。オプションの脱着式ペダルに変更すれば、折り畳み時の幅を最小化できます。
専用輪行バッグ・脱着式ペダル販売中
Anytime, anywhere.
Fun and small companion.
Easy, comfortable and performance
in a compact size. New folding model
for beginners to enthusiasts.
Slant Design
Slim, simple & rugged
IVE was born under a new design philosophy by Tyrell. It ensures that the beautiful design is rigid and functional for folding bicycles. Using chromoly steel which is strong frame material, will ensure that we are able to craft an original slim body design yet maintaining the rigidity of the frame. This sturdy and smart design makes the appearance of the rider more beautiful and distinctive.
Original Design
IVE’s unique originality is the slender and simple frame and rear truss structure
Intuitive Folding Mechanism
A major milestone in IVE is the development of a folding mechanism that is easy and convenient for everyone. A simple operation by just pushing the lever next to the handle to start folding.
An intuitively easy to understand operation technique is one of the key in IVE ‘s excellent design
A Meaningful Beauty
IVE frame is made from chromoly tubes, not pressed frames or large diameter pipes because we need to make it look slender and strong with minimum material and space. The special designed hydroforming downtube and the curved part of the seat stay are not merely designed but has necessary functions. There is no excessive design in the IVE, and all shapes have their functions.
Features
Like all Tyrell’s, the sporty riding performance remains intact. IVE is more fun, easy to handle and easy to fold.
Main features
・Chromoly Steel frame that promises subtle and comfortable ride
・4 Step Easy folding
・Original design folding front fork
・Slender and functional frame design
・One-touch parking lever. No kick stand required.
・High-performance wheels with sealed bearing hub
・Front and rear fender
・Low center of gravity and long wheel base for stable riding
高性能ホイールを標準装備
シールドベアリングハブ搭載の軽量・高性能ホイールを標準装備。※画像は2018年モデルです（現行モデルと一部仕様が異なります）
ピボット・一体成型BB
前後のフレームをつなぐピボットBB軸は、折畳み自転車の基本性能を決定する重要な部分。安定した走行のために一体成形し、コストをかけ性能向上を図っています。 ※画像は2018年モデルです（現行モデルと一部仕様が異なります）
熱処理されたダウンチューブ
一般的な折畳み自転車はトップチューブが1本のみの構造のため、強度不足による破断など重大なトラブルを引き起こす恐れがあります。IVEはダイヤモンド形状のフレームデザインを採用しこの問題を解決。ダウンチューブにはさらに熱処理を施すことで、フレーム剛性を向上させています。 ※画像は2018年モデルです（現行モデルと一部仕様が異なります）
見えない部分にもこだわりの性能
高性能なスポーツミニベロと同等のスペックで設計されているIVEのフレーム。ヘッドチューブは素材から切出したインテングラルヘッド方式（ベアリング一体式ヘッド）を採用、また挿入するベアリングもスポーツサイクル車と同規格のオーバーサイズ1-1/8”を使用しています。※画像は2018年モデルです（現行モデルと一部仕様が異なります）
トラス構造のリアフレーム
IVEの特徴的なデザインのひとつ、リアフレームのトラス構造。角パイプで構成された左右非対称のリアフレームは、折畳み時のクランクの干渉を防止するとともに、ぶれのない安定した走行性能に寄与します。 ※画像は2018年モデルです（現行モデルと一部仕様が異なります）
Safety is Top Priority
Extreme geometry affects handling and instability during riding, which is one of the minus points seen in many small wheel diameter folding bikes.
IVE was design from ground up to incorporate basic performance such as “ride comfort”, “folding mechanism” and “ease of use” from the design stage. Also by having the optimal wheelbase, low center of gravity body and handling efficiency, we ensure all riders will feel safe, stable and comfortable on the IVE.
Durability and Rigidity
In general, folding bicycles have many moving parts, designing and processing accuracy of those parts subject to loading is a very important point in making a safe body.
The moving part of the IVE has passed all durability tests of the EN standard, ensuring adequate rigidity. It is a proof of Tyrell ‘s high design technology.
Easy Parking
Just by pressing the lever (lock off lever) attached to the handle, the body will change itself to the parking position.
Special Elastomer
The rear frame is equipped with a suspension (elastomer) that alleviates shock from the rear wheel. You can enjoy comfortable riding even on uneven roads.
Rear Carrier
Optional rear carrier, exclusively designed to match the body of the IVE. Now you can roll the bike freely when folded as we have built in bearing in the mini wheels on the rack.
If you install the front bag carrier, the loading capacity will be greatly improved.
Special Wheel Bag
To accommodate various carrying/wheeling scenes, we have designed a bag that the bottom can be removed and exposed the *rack with wheels to enable rolling. The bag also comes with a shoulder strap for ease of carrying. A bag that can be use in various styles when transporting the bike.
* Please note that the rear carrier with wheels is sold separately *
High Performance Wheels
Lightweight and high performance wheels with sealed bearing hub.
Front Carrier Mounting
Equipped with a dowel hole in the head tube. If you install the Tyrell original TMS body or a third party adapter, you can install a front bag or basket
TMS（Tyrell Mounting System)
All IVE are TMS ready. TMS is a mounting system develop exclusively by Tyrell for all its bikes. Bikes with TMS adapter will be able to mount TM and TT Bags, which are exclusive Tyrell designed bags.
Geometry
A Wheel base: 1,058 mm
B Handle Post height: 970 to 1,000 mm
C Cockpit length: 611 to 641 mm
D Saddle height: 810 to 1,010 mm
E Standoff height: 585 mm
F Chain stay length: 420 mm
G Bottom bracket height: 286 mm
H Total length: 1,502 mm
Main Specifications：
· Frame: #4130 Chromoly Hydrofoamed
· Wheel: 18 inches (ETRTO 355) O.L.D: F 74 mm / R 120 mm
· Folding Fork: Aluminum Blade
· Speed change: 9 speed
· Seatpost: 33.9 x 530 mm
· Brake: V brake
· Finished car weight: 11.5 kg
Folding size: W 710 mm x H 590 mm x D 330
Color:
オプション：
[PURCHASE ONLY FROM JAPAN DOMESTIC CUSTOMER]
持ち運び
Carry
The first model to be designed based on Tyrell’s next generation folding bike concept (E. S. P Design)
The major point in this development is to make the folding operation method as easy and as convenient as possible. A simple operation to start folding by just pushing the lever (lock off lever) beside the handle. and it can transform the IVE to a compact size folded bike for storage inside the car, train or even at the cafe in just 4 simple and easy steps.
Can be carried by car
Go out on the weekend’s day off, driving a little far away. On your favorite spot, ride your favorite bike · · ·. It’s easy to fold, so you can easily carry around with a car.
Can be carried by train
After folding it can be carried comfortably by storing it in a dedicated wheel bag. Furthermore, by installing the optional rear carrier and bearing casters, you can roll it in a folded state by detaching the bottom of the wheel bag (※), and demonstrate its power by moving in the station.
※ It may be prohibited by rules of railroad company. Be sure to follow the instructions of each railway company.
Can be stored indoors
A height of 71 cm, a length of 59 cm, and a width of 33 cm are realized. Completed car size of 1,058 mm long wheelbase is surprisingly housed in a compact size. It does not take up space in indoor storage, it not only brings significant benefits to security crime, it can also protect your car from dust and scratches.
Folding procedure
No tools needed, just 4 steps. Easy and simple to follow.
Sale of exclusive wheel bag
Anytime, anywhere. Fun and small companion.
Easy, comfortable and performance in a compact size. New folding model for beginners to enthusiasts. お見積もりシミュレーション
Slant Design
Slim, simple & rugged
IVE was born under a new design philosophy by Tyrell. It ensures that the beautiful design is rigid and functional for folding bicycles. Using chromoly steel which is strong frame material, will ensure that we are able to craft an original slim body design yet maintaining the rigidity of the frame. This sturdy and smart design makes the appearance of the rider more beautiful and distinctive.
Original Design
IVE’s unique originality is the slender and simple frame and rear truss structure
Intuitive Folding Mechanism
A major milestone in IVE is the development of a folding mechanism that is easy and convenient for everyone. A simple operation by just pushing the lever next to the handle to start folding.
An intuitively easy to understand operation technique is one of the key in IVE ‘s excellent design
A Meaningful Beauty
IVE frame is made from chromoly tubes, not pressed frames or large diameter pipes because we need to make it look slender and strong with minimum material and space. The special designed hydroforming downtube and the curved part of the seat stay are not merely designed but has necessary functions. There is no excessive design in the IVE, and all shapes have their functions.
Features
Like all Tyrell’s, the sporty riding performance remains intact. IVE is more fun, easy to handle and easy to fold.
Main features
・Chromoly Steel frame that promises subtle and comfortable ride
・4 Step Easy folding
・Original design folding front fork
・Slender and functional frame design
・One-touch parking lever. No kick stand required.
・High-performance wheels with sealed bearing hub
・Front and rear fender
・Low center of gravity and long wheel base for stable riding
ナローホイール＆ナロータイヤ
タイヤをIVE標準の1.5㌅幅から1.25㌅幅に変更し、ホイール幅も最適化。
オフセットハンドルポスト
40mm前方にオフセットされた軽量（標準ステムより約90gの軽量化）のハンドルポストを装備
ライトシートポスト
全長540mm、標準シートポストと比較すると120ｇの軽量化を実現。重心から離れた高所を軽量化することにより、低重心化による安定感とシャープなハンドリングを実現しています。
リアウェイブショック
松村鋼機製スクロウェイブスプリングによるスペシャルショックを装備。エラストマーから機械バネに変更することで自然なストローク感となり、ソフトな乗車フィーリングを味わえます。また、サスが伸びきるまでの反発力が得られ、踏み込んだ際の瞬発力が高まり、キビキビとした走行フィーリングが得られます。
ロックオングリップ
FXに装着されているスポンジタイプのロックオングリップを標準装備。ソフトで握りやすいグリップにより、操作性と快適性がアップします。
Safety is Top Priority
Extreme geometry affects handling and instability during riding, which is one of the minus points seen in many small wheel diameter folding bikes.
IVE was design from ground up to incorporate basic performance such as “ride comfort”, “folding mechanism” and “ease of use” from the design stage. Also by having the optimal wheelbase, low center of gravity body and handling efficiency, we ensure all riders will feel safe, stable and comfortable on the IVE.
Durability and Rigidity
In general, folding bicycles have many moving parts, designing and processing accuracy of those parts subject to loading is a very important point in making a safe body.
The moving part of the IVE has passed all durability tests of the EN standard, ensuring adequate rigidity. It is a proof of Tyrell ‘s high design technology.
Easy Parking
Just by pressing the lever (lock off lever) attached to the handle, the body will change itself to the parking position.
Special Elastomer
The rear frame is equipped with a suspension (elastomer) that alleviates shock from the rear wheel. You can enjoy comfortable riding even on uneven roads.
Rear Carrier
Optional rear carrier, exclusively designed to match the body of the IVE. Now you can roll the bike freely when folded as we have built in bearing in the mini wheels on the rack.
If you install the front bag carrier, the loading capacity will be greatly improved.
Special Wheel Bag
To accommodate various carrying/wheeling scenes, we have designed a bag that the bottom can be removed and exposed the *rack with wheels to enable rolling. The bag also comes with a shoulder strap for ease of carrying. A bag that can be use in various styles when transporting the bike.
* Please note that the rear carrier with wheels is sold separately *
High Performance Wheels
Lightweight and high performance wheels with sealed bearing hub.
Front Carrier Mounting
Equipped with a dowel hole in the head tube. If you install the Tyrell original TMS body or a third party adapter, you can install a front bag or basket
TMS（Tyrell Mounting System)
All IVE are TMS ready. TMS is a mounting system develop exclusively by Tyrell for all its bikes. Bikes with TMS adapter will be able to mount TM and TT Bags, which are exclusive Tyrell designed bags.
Geometry
A Wheel base: 1,058 mm
B Handle Post height: 970 to 1,000 mm
C Cockpit length: 611 to 641 mm
D Saddle height: 810 to 1,010 mm
E Standoff height: 585 mm
F Chain stay length: 420 mm
G Bottom bracket height: 286 mm
H Total length: 1,502 mm
Main Specifications：
· Frame: #4130 Chromoly Hydrofoamed
· Wheel: 18 inches (ETRTO 355) O.L.D: F 74 mm / R 120 mm
· Folding Fork: Aluminum Blade
· Speed change: 9 speed
· Seatpost: 33.9 x 530 mm
· Brake: V brake
· Finished car weight: 11.5 kg
Folding size: W 710 mm x H 590 mm x D 330
Color:
オプション：
[PURCHASE ONLY FROM JAPAN DOMESTIC CUSTOMER]
持ち運び
Carry
The first model to be designed based on Tyrell’s next generation folding bike concept (E. S. P Design)
The major point in this development is to make the folding operation method as easy and as convenient as possible. A simple operation to start folding by just pushing the lever (lock off lever) beside the handle. and it can transform the IVE to a compact size folded bike for storage inside the car, train or even at the cafe in just 4 simple and easy steps.
Can be carried by car
Go out on the weekend’s day off, driving a little far away. On your favorite spot, ride your favorite bike · · ·. It’s easy to fold, so you can easily carry around with a car.
Can be carried by train
After folding it can be carried comfortably by storing it in a dedicated wheel bag. Furthermore, by installing the optional rear carrier and bearing casters, you can roll it in a folded state by detaching the bottom of the wheel bag (※), and demonstrate its power by moving in the station.
※ It may be prohibited by rules of railroad company. Be sure to follow the instructions of each railway company.
Can be stored indoors
A height of 71 cm, a length of 59 cm, and a width of 33 cm are realized. Completed car size of 1,058 mm long wheelbase is surprisingly housed in a compact size. It does not take up space in indoor storage, it not only brings significant benefits to security crime, it can also protect your car from dust and scratches.
Folding procedure
No tools needed, just 4 steps. Easy and simple to follow.
Sale of exclusive wheel bag
RX. Feel the sense of iron
Modern steel road bike with the charm of
organic dampening vibration
for a comfortable ride.
Design
Steel Road RX, is a pure domestic production model that highlights the comfort of the steel for long rides.
This modern steel road racer consists of a standard diamond shape frame with slender pipes, but equipped with high-performance parts of the latest technology such as large diameter heads and full carbon forks. It forms a modern blend of road racers where nostalgic atmosphere and freshness live together.
A rigid feeling that makes even the heavier rider feel safe or on fast downhill where the bike feels stable. This is one bike that makes riding smooth, comfortable and stable.
COLUMBUS Steel.
Lightweight and High Performance.
We use the famous high-performance lightweight steel pipe made by Columbus, Italy for the main tube. This helps us to achieve the frame weight of 1.5 kg. It is lightweight and highly rigid, so you can experience the feeling of traveling comfort even on a long ride
Frame Design
The elliptical irregular shaped chromoly tube is used everywhere. The front triangle is slightly sloping, and the seat stay is vented to S shape for Modern design. The front triangle (which keeps rigidity around the down tube) and the back triangle is design to enhance the absorption of vibration in order to keep the balance when on high speed.
Geometry
To accommodate the rider ‘s riding position, we have 9 frame sizes to choose from, ranging from size 470mm to 555mm seat tube length.
For frame size 510mm or larger, the geometry design is base on the rider’s physique and power such as quenched seat stay for optimum power transfer.
Powder Coating Paint
Powder coating by Kadowaki Coating (Yokohama City, Kanagawa Prefecture) creates a beautiful and durable paint finish on the RX that is mesmerising.
Full Domestic Production
Everything from development to manufacturing is done domestically, under strict quality and accuracy control system. Each piece is done part by part by our craftsmen with emphasis on accuracy and detail to show our the commitment in producing the steel road racer RX.
TIG (Tungsten Inert Gas) welding at the joints of tubes and powder coating on the frame is like an art itself. This high quality steel road racer can only be produced by hand, one piece at a time.
Features
The characteristics of a pure racing bike made from steel for long and enjoyable ride.
Main features
· Frames under strict quality control, and produce at our factory
· High performance Itallian Columbus tubing that makes lightweight steel, is used for the main tube
· Beautiful slender tubes
· Frame design fully compatible with latest drive train components
– Variety of sizes available (9 sizes in all)
· High performance full carbon ENVE fork
· Powder coating by Kadowaki Coating Company for the perfect paint finish and durability. Custom colours available on request.
· Stolen recovery support
ベアリング内蔵BBホビット・クランクセット2
BB周りの剛性を確保するために、BB下のにベアリング内蔵のピポットを設計。これを回転軸に、リアホイールが、180°展開します。その際、折畳み時のチェーン脱落を考慮し、56T・CNC製のチェーンガードを装着。標準仕様は、53Tのシングルチェーンリング、ホローテック方式のクランク・BBの採用。
A Comfortable Sense of Unity with the Body that fascinates Veteran Riders
RX which modernized the performance by adopting large diameter headset and full carbon fork while leaving a feeling of riding a steel bike which is comfortable but stiff.A good quality frame with a core that gently synchronizes to the movement of a rider yet does not loose it rigidness to the state-of-the-art carbon frame despite being steel. This feeling will fascinates the veteran riders.
ENVE High Performance Full Carbon Fork
ENVE full carbon fork is used to because of its high-performance carbon with the latest technology. It is highly resistant to twisting, make steering more stable and with its high vibration absorption will contribute to the performance of RX.
仕様
Geometry
A ホイールベース：1075mm
B シートチューブ長（C-T）：390mm
C 仮想トップチューブ長（水平）：558mm
D ヘッドチューブ角：70.0°
シートチューブ角：73.0°
F チェーンステー長：431mm
G ボトムプランケット高：273mm
H 全長：1,545mm
Main Specifications：
· Frame: COLUMBUS LIFE Chromoly Tubing
· Wheel: ULTEGRA WH-RS 500
– Standard color: Pearl white by Kadowaki powder coating
· Fork: ENVE 2.0 FORK matte black (logo: white)
· Shift: 2×11 speed
· Tires: SCHWALBE DURANO Folding 700c
· Component: SHIMANO ULTEGRA R 8000 series
– Frame weight: 500 mm / 1,700 g (※), 525 mm / 1,750 g * Weight of frame alone
Customization options：
･ Frame custom color: 1 color choice from class 1 or 2 colors (Tyrell color order sample book) free
･ Fork custom color: 1 color selection from class 1 (Tyrell color order sample book)(※) 10,000 yen + tax
※ Acrylic paint (it will be approximate color)
Other：
· Stem length change (selected from 80 mm, 90 mm, 100 mm, 110 mm): Free
· Drop handle width change (selected from 360 mm, 380 mm, 400 mm, 420 mm): Free
· Bar tape color change (selected from black, red): free
Color:
» Specification with RX Pearl White Shimano Ultegra(¥ 392,000 - / not including tax. Front folk using Black color in Sales model)
オプション：
Custom Colour Order
Frame colors can be painted in your favorite colors (charged option). You can choose the color of the decal too to make the RX truly personalised.
» Color pattern
CSI.The Spartan
Fast acceleration
and sharp handling.
CSI is the ultimate hybrid minivelo.
Slant Design
CSI is designed by weaving together a distinctive thin large diameter aluminium frame and beautiful carbon rear triangle.
A utility bike endorsed by riders due to its performance and sharpness because of its super lightweight body and specifications. The frame design has a common design code which is the “slant design” adopting the two narrow inclined pipes sandwiching the top tube. The silhouette of the impressive frame design not only lies in the design, but also on the unique minivelo framework that will contribute to increase the strength of the entire frame as well as the rigidity around the long head tube. High torsional rigidity due to this slant effect and low center of gravity because of the geometry plus using the strongest yet lightweight #7005 aluminium alloy series and pair it with a rear carbon triangle will create an explosive acceleration feeling and sharp handling which road bike’s cannot give. The CSI is compatible to install the Shimano Di2 electronic drive train. It’s smooth, beautiful welding and attention to detail is the perfect one for those who pursues real fun.
Attractive Frame Design
“Slant Tube” is when two tubes extending from the head tube to the top tube creates an exceptional beauty when viewed from the back. Furthermore, the unique shape down tube enhances the rigidity which is the uniqueness of the CSI.
Craftsmanship Detailing
The smooth welding on the aluminium 7005 frame for light weight and high rigidness requires the welding beads to be carefully polished. This attention to the smallest details is to ensure the CSI is beautifully and skilfully done.
The New Carbon Rear Triangle
Using carbon material for high vibration absorbing purposes on the chain and seat stay, also adds to the beauty of the CSI.
Around the BB Design
Three places around the bottom bracket are welded to increase the frame strength. The Chainstay which is fixed by a special adhesive, brings out a tremendous rigid feeling beyond imagination.
Features
The main frame is made from aluminium 7005 material and using full carbon rear triangle, create a light weight with super vibration absorption minivelo that is performance ready.
Main features
· Lightweight Hybrid 7005 Aluminum Frame & Carbon Rear Triangle
· Frame design compatible to fit all road drive trains
· Craftsmanship in the detailed welding finish and top of with Kadowaki powder coating
· Ideal frame for both light weight and high rigidity
· Unique shaped down tube to increase rigidity
· Full carbon monocoque fork that promises lightweight and ride comfort
· High-performance AM3 wheels with sealed bearing hub
· Di2 ready with internal wiring
· Low center of gravity and long wheel base for stable riding
· A wide range of specifications are available according to the riding style, from handlebar types to different drive train settings
· Stolen recovery support support
高性能ホイール、AM-3を標準装備
シールドベアリングハブ搭載の軽量・高性能ホイールを標準装備（AM-3）。抜群の回転性能と、20インチ451サイズならではの走破性を活かした走りを味わえます。また、追加オプションで上位グレードのホイールへアップグレード（AM-9 Plus）も可能、走りの性能がさらに高まります。
精悍さをアピールする、ツートンカラー
2020イヤーモデルは、レーシーな面持ちのCSiをさらに際立たせる、グロス（艶あり）とマットブラック（艶なし）のツートンカラー。グロス部分は、4色の中からあなたのセンスに合ったカラーをお選びいただけます。
Di2コンポ対応
フレームアタッチメントを交換すれば、最新のシマノDi2コンポーネントにも対応可能。エレクトリックケーブルもフレーム内にすっきりと内蔵できます。
The Lightness
High torsional rigidity by the slant tube with low center of gravity and long wheel base allows you to enjoy a sense of stability on the CSI.
In addition, by pairing the rigid aluminium frame with the flexibility of carbon to create a light weight frame makes acceleration on the CSI a truly enjoyable feeling.
Lightweight Full Carbon Monocoque Fork
A lightweight full carbon monocoque fork which is excellent for vibration absorption is used for delivering a light and comfortable ride.
High-Performance AM-3 Wheels
Lightweight, high-performance wheel with sealed bearing hub (AM-3) on the 20 inch 451 size delivers excellent rotation performance and unique riding experience.In addition, you can opt to upgrade to a higher grade wheels, the AM – 9 Plus which churns out even better riding performance.”
Equipped with High End Shimano Components
The standard CSI is equipped with high-grade Shimano Ultegra R8000 series, which is smooth, reliable and robust to compliment the CSI.
仕様
Geometry
A Wheelbase: 1,034 mm
B Seat tube length (C – T): 405 mm
C Virtual top tube length (horizontal): 545 mm
D Head tube angle: 71.0 °
E Seat tube angle: 73.5 °
F Chain stay length: 425 mm
G Bottom bracket height: 272 mm
H Total length: 1,545 mm
Main Specifications：
· Frame: Aluminum #7005 Double Butted Tube
· Wheel: 20 inches (ETRTO 451) O.L.D: F 100 mm / R130 mm
· Fork: 3K carbon monocoque
· Speed change: 11 speed
· Frame weight: 2,150 g * Weight including frame, fork, head part, top cover
· Complete weight (not including pedals): 7.5 kg (drop handlebar model)
Flat model Specification Drop model Specification
Equipment / Components / Shimano ULTEGRA R8000 drop model：
· Wheel set: AM-3 451 Silver, F24 R2 8H
· Tire: SCHWALBE DURANO 20 “x 11/8 (451 x 28)
· Front derailleur: Shimano ULTEGRA FD-R 8000
· Rear derailleur: Shimano ULTEGRA RD – R 8000 11 Speed
· Shifter: Shimano ULTEGRA ST-R 8000
· Cassette: Shimano ULTEGRA CS-R 800011-25T 11 speed
· Chain: CN-HG 701 – 11
· Crankset: Crankset: Shimano ULTEGRA FC-R 8000 53 x 39 T 170 mm
· Brake caliper: Shimano ULTEGRA BR-R 8000
· Saddle: Prologo NAGO EVO T1.4
· Seatpost: # 7075 Alloy, D 31.6 x 400 mm
· Stem: Tyrell Road Stem 31.8 x L 80/90/100/110 mm
· Handlebar: Tyrell #7050 Aluminum d 31.8 x W 360 mm / 380 mm / 400 mm / 420 mm
Custom Specification ：
・It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The CSI is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the CSI with parts of your choice.
・Theft Recovery Support
Our theft recovery support will enable you to repurchase a new CSI (only once) at a lower price if the theft occurs inside one year from the date of purchase.
Standard color:
オプション：
[PURCHASE ONLY FROM JAPAN DOMESTIC CUSTOMER]
Custom Specification
It is possible to select one of your favourite specifications from a wide range of choices according to budget and riding style. This includes handlebar type and and your preferred drive trains. The FX is compatible with all the latest drive trains, so it is possible to just purchase the frame and custom build the FX with parts of your choice.
